The NanoPi NEO Plus2 is another Allwinner based ARM board developed by FriendlyElec. It uses Allwinner's 64-bit quad-core A53 SoC with hexa-core Mali450 GPU and features 1GB of DDR3 RAM and 8GB eMMC.
With a small size of only 40 x 52mm the NanoPi NEO Plus2 has rich on-board resources: AP6212A WiFi & Bluetooth module, Gbps Ethernet and two USB hosts. It supports system-boot from a MicroSD card.
The NanoPi NEO Plus2 has a carefully designed power system and 6-layer PCB layout. These features enhance the board's heat dissipation.
The NanoPi NEO Plus2 meets popular IOT applications requirements for small size, high-speed and large throughput data transmission and high performance computing.
Link to purchase:NanoPi NEO Plus2

Nano
  • SoC: Allwinner H5,Quad-core 64-bit high-performance Cortex A53
  • DDR3 RAM:1GB
  • Storage: 8GB eMMC
  • Network: 10/100/1000M Ethernet based on RTL8211E-VB-CG
  • WiFi: 802.11b/g/n
  • Bluetooth: 4.0 dual mode
  • MicroSD Slot: 1 x Slot. It supports system booting or is used to hold a storage card
  • Audio Input/Output: 5-Pin, 2.0mm pitch pin-header
  • MicroUSB: power input
  • Debug Serial: 4Pin, 2.54mm pitch pin-header
  • GPIO1:24Pin, 2.51mm pitch double-row pin-header containing UART, SPI, I2C and IO
  • GPIO2:12Pin, 2.54mm pitch pin-header containing USB, IR receiver,I2S and IO
  • Power Supply: DC 5V/2A
  • PCB Dimension: 40 x 52mm
  • PCB Layer: 6-Layer

PreviousNext
Nano signal slot booster
Software Features(UbuntuCore)
  • mainline kernel: Linux-4.x.y
  • 64-bit OS
  • npi-config: system configuration utility for setting passwords, language, timezone, hostname, SSH and auto-login.
  • auto-login with user account 'pi' with access to npi-config
  • supports Gbps Ethernet
  • supports WiFi and Bluetooth
  • supports FriendlyElec's FA-CAM202 USB camera
  • supports audio recording and playing
Nano signal slot app
Diagram, Layout and Dimension

GPIO Pin Spec

Pin# Name Linux gpio Pin# Name Linux gpio
1 SYS_3.3V 2 VDD_5V
3 I2C0_SDA / GPIOA12 12 4 VDD_5V
5 I2C0_SCL / GPIOA11 11 6 GND
7 GPIOG11 203 8 UART1_TX / GPIOG6 198
9 GND 10 UART1_RX / GPIOG7 199
11 UART2_TX / GPIOA0 0 12 GPIOA6 6
13 UART2_RTS / GPIOA2 2 14 GND
15 UART2_CTS / GPIOA3 3 16 UART1_RTS / GPIOG8 200
17 SYS_3.3V 18 UART1_CTS / GPIOG9 201
19 SPI0_MOSI / GPIOC0 64 20 GND
21 SPI0_MISO / GPIOC1 65 22 UART2_RX / GPIOA1 1
23 SPI0_CLK / GPIOC2 66 24 SPI0_CS / GPIOC3 67
Nano signal slot car

Nano Signal Slot Booster


USB/Audio/IR Pin Description

NanoPi NEO Plus2
Pin# Name Description
1 VDD_5V 5V Power Out
2 USB-DP1 USB1 DP Signal
3 USB-DM1 USB1 DM Signal
4 USB-DP2 USB2 DP Signal
5 USB-DM2 USB2 DM Signal
6 GPIOL11 / IR-RX GPIOL11 or IR Receive
7 SPDIF-OUT / GPIOA17 GPIOA17 or SPDIF-OUT
8 PCM0_SYNC / I2S0_LRC I2S / PCM Sample Rate Clock/Sync
9 PCM0_CLK / I2S0_BCK I2S / PCM Sample Rate Clock
10 PCM0_DOUT / I2S0_SDOUT I2S / PCM Serial Data Output
11 PCM0_DIN / I2S0_SDIN I2S / PCM Serial Data Input
12 GND 0V

Audio

Pin# Name Description
1 MICIN1P Microphone Positive Input
2 MICIN1N Microphone Negative Input
3 LINEOUTR LINE-OUT Right Channel Output
4 GND 0V
5 LINEOUTL LINE-OUT Left Channel Output

Debug Port(UART0)

Pin# Name
1 GND
2 VDD_5V
3 UART_TXD0 / GPIOA4
4 UART_RXD0 / GPIOA5 / PWM0
Note:
  1. SYS_3.3V: 3.3V power output
  2. VVDD_5V: 5V power input/output. The input range is 4.7V ~ 5.6V
  3. All pins are 3.3V, output current is 5mA
  4. For more details refer to the document: NanoPi-NEO-Plus2-1704-Schematic.pdf
